| Manufacturer Product Number | AD1341KZ |
| Manufacturer | Analog Devices Inc. |
| NavitasChip Part Number | NAVI-12103945 |
| Description | 16-CHANNEL DATA AQ SYSTEM |
| Spec | 100-BCQFP |
| Package | Bulk |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Analog to Digital Converters (ADC) |
| Manufacturer | Analog Devices Inc. |
| Package | Bulk |
| Product Status | Active |
| Number of Bits | 12 |
| Number of Inputs | 1 |
| Input Type | Differential, Single Ended |
| Data Interface | Parallel |
| Configuration | MUX-PGA-S/HADC |
| Ratio - S/H | 1:1 |
| Number of A/D Converters | 1 |
| Reference Type | External |
| Voltage - Supply, Analog | 4.75V ~ 5.25V, ±14.25V ~ 15.75V |
| Voltage - Supply, Digital | 4.75V ~ 5.25V, ±14.25V ~ 15.75V |
| Operating Temperature | 0°C ~ 70°C |
| Supplier Device Package | 4-STSTAMP™ (0.47x0.47) |
| Mounting Type | Surface Mount |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc. AD1341KZ Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The AD1341KZ is an Analog-to-Digital Converter (ADC) manufactured by Analog Devices Inc. (ADI). 16-Channel Data Aq System, housed in a compact 4-STSTAMP™ (0.47x0.47) package.
Key Technical Specifications
- Operating Temperature: 0°C ~ 70°C
- Mounting: Surface Mount
- Package: 100-BCQFP
- Device Package: 4-STSTAMP™ (0.47x0.47)
Packaging: factory Bulk or Custom Quantity · ESD-shielded, vacuum-sealed MBB to MSL standards.
Fulfillment: MPN and Date Code verified on inbound · datasheet and compliance documents available · RFQ answered within 24 hours.
