| Manufacturer Product Number | AD7293BCPZ |
| Manufacturer | Analog Devices Inc. |
| NavitasChip Part Number | NAVI-6163949 |
| Description | IC POWER AMPLIFIER 12BIT 56LFCSP |
| Spec | 56-WFQFN Exposed Pad, CSP |
| Package | Tray |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | ADCs/DACs - Special Purpose |
| Manufacturer | Analog Devices Inc. |
| Package | Tray |
| Product Status | Active |
| Type | Power Amplifier |
| Number of Channels | 4 |
| Resolution (Bits) | 12 b |
| Data Interface | Serial, SPI |
| Voltage Supply Source | Single Supply |
| Voltage - Supply | ±4.5V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 56-LFCSP-WQ (8x8) |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc. AD7293BCPZ Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The AD7293BCPZ is an Audio Codec and Special-Purpose Data Converter IC manufactured by Analog Devices Inc. (ADI). Integrated Circuit Power Amplifier 12bit in 56-Pin Csp Package, housed in a compact 56-LFCSP-WQ (8x8) package, with ±4.5V ~ 5.5V supply voltage.
Key Technical Specifications
- Supply Voltage: ±4.5V ~ 5.5V
- Channels: 4
- Operating Temperature: -40°C ~ 125°C
- Mounting: Surface Mount
- Package: 56-WFQFN Exposed Pad, CSP
- Device Package: 56-LFCSP-WQ (8x8)
- RoHS Compliant
Packaging: factory Tray or Partial Tray · ESD-shielded, vacuum-sealed MBB to MSL standards.
Fulfillment: MPN and Date Code verified on inbound · datasheet and compliance documents available · RFQ answered within 24 hours.
Disclaimer: NavitasChip is an independent distributor of electronic components. We are not affiliated with, endorsed by, or an authorized distributor for the manufacturers listed on this page. All trademarks and brand names are the property of their respective owners and are used solely for identification purposes.
Stock quantities are dynamic and updated in real-time. For large quantity orders (1,000+ units), please contact us for real-time stock verification and custom pricing.
