| Manufacturer Product Number | AD7747ARUZ |
| Manufacturer | Analog Devices Inc. |
| NavitasChip Part Number | NAVI-807741 |
| Description | IC CAP TO DGT CONV 24BIT 16TSSOP |
| Spec | 16-TSSOP (0.173", 4.40mm Width) |
| Package | Tube |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | ADCs/DACs - Special Purpose |
| Manufacturer | Analog Devices Inc. |
| Package | Tube |
| Product Status | Active |
| Type | Capacitance-to-Digital Converter |
| Number of Channels | 2 |
| Resolution (Bits) | 24 b |
| Data Interface | Serial |
| Voltage Supply Source | Single Supply |
| Voltage - Supply | 2.7V ~ 5.25V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 16-TSSOP |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc. AD7747ARUZ Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The AD7747ARUZ is an Audio Codec and Special-Purpose Data Converter IC manufactured by Analog Devices Inc. (ADI). Integrated Circuit Cap to Dgt Converter 24bit in 16-Pin TSSOP Package, housed in a compact 16-TSSOP package, with 2.7V ~ 5.25V supply voltage.
Struggling with discontinued AD2S resolver-to-digital and AMC1 isolated ADC families requiring drop-in replacements? Our global sourcing network ensures reliable supply for your projects.
Key Technical Specifications
- Supply Voltage: 2.7V ~ 5.25V
- Channels: 2
- Operating Temperature: -40°C ~ 125°C
- Mounting: Surface Mount
- Package: 16-TSSOP (0.173", 4.40mm Width)
- Device Package: 16-TSSOP
- RoHS Compliant
