| Manufacturer Product Number | LTC1294DCJ |
| Manufacturer | Analog Devices Inc. |
| NavitasChip Part Number | NAVI-297145 |
| Description | 12-BIT SERIAL I/O ADC W/8 CH MUX |
| Spec | 20-CDIP (0.300", 7.62mm) |
| Package | Tube |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | ADCs/DACs - Special Purpose |
| Manufacturer | Analog Devices Inc. |
| Package | Tube |
| Product Status | Obsolete |
| Type | Data Acquisition System (DAS), ADC |
| Number of Channels | 8 |
| Resolution (Bits) | 12 b |
| Sampling Rate (Per Second) | 46.5k |
| Data Interface | Serial, Parallel |
| Voltage Supply Source | Dual ± |
| Voltage - Supply | ±5V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole |
| Supplier Device Package | 20-CERDIP |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc. LTC1294DCJ Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The LTC1294DCJ is an Audio Codec and Special-Purpose Data Converter IC manufactured by Analog Devices Inc. (ADI). 12-Bit Serial I/o Analog-To-Digital Converter W/8-Channel Multiplexer, housed in a compact 20-CERDIP package, with ±5V supply voltage. Originally developed by Linear Technology.
Key Technical Specifications
- Supply Voltage: ±5V
- Channels: 8
- Operating Temperature: 0°C ~ 70°C
- Mounting: Through Hole
- Package: 20-CDIP (0.300", 7.62mm)
- Device Package: 20-CERDIP
Packaging: factory Tube or Custom Tube Quantity · ESD-shielded, vacuum-sealed MBB to MSL standards.
Fulfillment: MPN and Date Code verified on inbound · datasheet and compliance documents available · RFQ answered within 24 hours.
Disclaimer: NavitasChip is an independent distributor of electronic components. We are not affiliated with, endorsed by, or an authorized distributor for the manufacturers listed on this page. All trademarks and brand names are the property of their respective owners and are used solely for identification purposes.
Stock quantities are dynamic and updated in real-time. For large quantity orders (1,000+ units), please contact us for real-time stock verification and custom pricing.
