| Manufacturer Product Number | LTC1322CSW#TR |
| Manufacturer | Analog Devices Inc. |
| NavitasChip Part Number | NAVI-693704 |
| Description | IC TXRX RS232/485/EIA562 24SOIC |
| Spec | 24-SOIC (0.295", 7.50mm Width) |
| Package | Tape & Reel (TR) |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Drivers, Receivers, Transceivers |
| Manufacturer | Analog Devices Inc. |
| Package | Tape & Reel (TR) |
| Product Status | Discontinued at |
| Type | Transceiver |
| Protocol | RS562 |
| Number of Drivers/Receivers | 6/6 |
| Duplex | Full |
| Receiver Hysteresis | 70 mV |
| Voltage - Supply | 4.75V ~ 5.25V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 24-SOIC |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc. LTC1322CSW#TR Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The LTC1322CSW#TR is an Interface Driver Receiver Transceiver IC manufactured by Analog Devices Inc. (ADI). Integrated Circuit Transceiver RS-232/485/eia562 in 24-Pin SOIC Package, housed in a compact 24-SOIC package, with 4.75V ~ 5.25V supply voltage. Originally developed by Linear Technology, this component continues to be fully supported. Supplied in Tape and Reel packaging for automated assembly.
Struggling with discontinued CAN and LIN transceivers requiring drop-in replacements? Our global sourcing network ensures reliable supply for your projects.
Key Technical Specifications
- Supply Voltage: 4.75V ~ 5.25V
- Operating Temperature: 0°C ~ 70°C
- Mounting: Surface Mount
- Package: 24-SOIC (0.295", 7.50mm Width)
- Device Package: 24-SOIC
- RoHS Compliant
Applications
Engineered specifically for:
- professional equipment
- 5G CPE and small cell base station interfaces
- building automation BACnet and KNX network communication
- smart grid metering and substation communication
- LVDS and high-speed serial drivers for backplane and inter-board links
Why Choose NavitasChip for LTC1322CSW#TR?
NavitasChip offers cost-saving procurement for the LTC1322CSW#TR and thousands of other electronic components.
- Availability: Immediate Dispatch Available
- Packaging: Available in factory Tape & Reel (TR) or Cut Tape. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
As an independent distributor, we offer LTC1322CSW#TR with flexible routing options.
LTC1322CSW#TR - Get instant quote online.
