| Manufacturer Product Number | LTC1409CG |
| Manufacturer | Analog Devices Inc. |
| NavitasChip Part Number | NAVI-255280 |
| Description | IC A/D CONV 12BIT SAMPLNG 28SSOP |
| Spec | 28-SSOP (0.209", 5.30mm Width) |
| Package | Tube |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Analog to Digital Converters (ADC) |
| Manufacturer | Analog Devices Inc. |
| Package | Tube |
| Product Status | Discontinued at |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 800k |
| Number of Inputs | 1 |
| Input Type | Differential, Single Ended |
| Data Interface | Parallel |
| Configuration | S/H-ADC |
| Ratio - S/H | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | ±5V |
| Voltage - Supply, Digital | 5V |
| Operating Temperature | 0°C ~ 70°C |
| Supplier Device Package | 28-SSOP |
| Mounting Type | Surface Mount |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc. LTC1409CG Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The LTC1409CG is an Analog-to-Digital Converter (ADC) manufactured by Analog Devices Inc. (ADI). Integrated Circuit Analog-To-Digital Converter 12bit Samplng in 28-Pin SSOP Package, housed in a compact 28-SSOP package. Originally developed by Linear Technology, this component continues to be fully supported.
Struggling with discontinued multi-channel ADC families requiring drop-in pin-compatible replacements? Our global sourcing network ensures reliable supply for your projects.
Key Technical Specifications
- Operating Temperature: 0°C ~ 70°C
- Mounting: Surface Mount
- Package: 28-SSOP (0.209", 5.30mm Width)
- Device Package: 28-SSOP
- RoHS Compliant
Applications
Essential component for:
- differential input ADC with on-chip reference and PGA for low-level signals
- 16-bit and 18-bit high-resolution ADC for instrumentation and process control
- megasample-per-second (MSPS) sampling for communication and imaging front-ends
- industrial process control and sensor signal conditioning data paths
- portable battery-powered handheld instrumentation and field test equipment
Why Choose NavitasChip for LTC1409CG?
NavitasChip offers competitive market pricing for the LTC1409CG and thousands of other electronic components.
- Availability: Immediate Dispatch Available
- Packaging: Available in factory Tube or Custom Tube Quantity. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
Multiple origin options for LTC1409CG to optimize delivery time and customs clearance.
LTC1409CG - Inquire for bulk discount.
