| Manufacturer Product Number | MAX1338ETN+T |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| NavitasChip Part Number | NAVI-11485680 |
| Description | IC ADC 14BIT SAR 56TQFN |
| Spec | 56-WFQFN Exposed Pad |
| Package | Tape & Reel (TR) |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Analog to Digital Converters (ADC) |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| Number of Bits | 14 |
| Sampling Rate (Per Second) | 150k |
| Number of Inputs | 4 |
| Input Type | Differential |
| Data Interface | Serial |
| Ratio - S/H | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | 4.75V ~ 5.25V |
| Voltage - Supply, Digital | 4.75V ~ 5.25V |
| Features | Simultaneous Sampling |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 56-TQFN (8x8) |
| Mounting Type | Surface Mount |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc./Maxim Integrated MAX1338ETN+T Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The MAX1338ETN+T is an Analog-to-Digital Converter (ADC) manufactured by Analog Devices Inc./Maxim Integrated (ADI-Maxim). Integrated Circuit Analog-To-Digital Converter 14bit Sar 56tqfn, housed in a compact 56-TQFN (8x8) package. Originally developed by Maxim Integrated, this component continues to be fully supported.
In today's market, hard-to-find Linear LTC and Maxim MAX legacy ADC with original date codes and traceability can affect many manufacturers. NavitasChip offers dependable alternatives.
Key Technical Specifications
- Operating Temperature: -40°C ~ 85°C
- Mounting: Surface Mount
- Package: 56-WFQFN Exposed Pad
- Device Package: 56-TQFN (8x8)
- RoHS Compliant
Applications
Widely adopted for:
- IoT devices
- professional equipment
- delta-sigma ADC for high-resolution sensor measurement and weighing systems
- flash and subranging ADC for ultra-high-speed waveform digitization
- integrated-reference low-power ADC for always-on battery-powered measurement
Why Choose NavitasChip for MAX1338ETN+T?
NavitasChip offers obsolete part procurement when authorized distributors discontinue support for the MAX1338ETN+T and thousands of other electronic components.
- Availability: Available Now
- Packaging: Available in factory Tape & Reel (TR) or Cut Tape. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
Fast MAX1338ETN+T delivery to Germany and France via DHL, FedEx, and UPS.
MAX1338ETN+T - Inquire for bulk discount.
