| Manufacturer Product Number | MAX4022ESD |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| NavitasChip Part Number | NAVI-12113939 |
| Description | GAIN OF 2 BUFFER WITH R-R O/P |
| Spec | 14-SOIC (0.154", 3.90mm Width) |
| Package | Bulk |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Instrumentation, OP Amps, Buffer Amps |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Package | Bulk |
| Product Status | Active |
| Amplifier Type | Buffer, Voltage Feedback |
| Number of Circuits | 4 |
| Output Type | Rail-to-Rail |
| Slew Rate | 600V/µs |
| -3db Bandwidth | 200 MHz |
| Current - Input Bias | 5.4 µA |
| Voltage - Input Offset | 4 mV |
| Current - Supply | 5.5mA (x4 Channels) |
| Current - Output / Channel | 120 mA |
| Voltage - Supply Span (Min) | 3.15 V |
| Voltage - Supply Span (Max) | 11 V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOIC |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc./Maxim Integrated MAX4022ESD Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The MAX4022ESD is an Operational Amplifier (Op Amp) manufactured by Analog Devices Inc./Maxim Integrated (ADI-Maxim). Gain of 2 Buffer with R-R O/p, housed in a compact 14-SOIC package. Originally developed by Maxim Integrated.
Key Technical Specifications
- Output Type: Rail-to-Rail
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting: Surface Mount
- Package: 14-SOIC (0.154", 3.90mm Width)
- Device Package: 14-SOIC
Packaging: factory Bulk or Custom Quantity · ESD-shielded, vacuum-sealed MBB to MSL standards.
Fulfillment: MPN and Date Code verified on inbound · datasheet and compliance documents available · RFQ answered within 24 hours.
