| Manufacturer Product Number | CS5102A-JLZ |
| Manufacturer | Cirrus Logic Inc. |
| NavitasChip Part Number | NAVI-923200 |
| Description | IC ADC 16BIT SAR 28PLCC |
| Spec | 28-LCC (J-Lead) |
| Package | Tube |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Analog to Digital Converters (ADC) |
| Manufacturer | Cirrus Logic Inc. |
| Package | Tube |
| Product Status | Obsolete |
| Number of Bits | 16 |
| Sampling Rate (Per Second) | 20k |
| Number of Inputs | 2 |
| Input Type | Single Ended |
| Data Interface | SPI |
| Configuration | S/H-ADC |
| Ratio - S/H | 1:1 |
| Number of A/D Converters | 1 |
| Architecture | SAR |
| Reference Type | External |
| Voltage - Supply, Analog | ±5V |
| Voltage - Supply, Digital | ±5V |
| Operating Temperature | 0°C ~ 70°C |
| Supplier Device Package | 28-PLCC (11.51x11.51) |
| Mounting Type | Surface Mount |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Cirrus Logic Inc. CS5102A-JLZ Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The CS5102A-JLZ is an Analog-to-Digital Converter (ADC) manufactured by Cirrus Logic Inc. (Cirrus). Integrated Circuit Analog-To-Digital Converter 16bit Sar 28plcc, housed in a compact 28-PLCC (11.51x11.51) package.
Key Technical Specifications
- Operating Temperature: 0°C ~ 70°C
- Mounting: Surface Mount
- Package: 28-LCC (J-Lead)
- Device Package: 28-PLCC (11.51x11.51)
Packaging: factory Tube or Custom Tube Quantity · ESD-shielded, vacuum-sealed MBB to MSL standards.
Fulfillment: MPN and Date Code verified on inbound · datasheet and compliance documents available · RFQ answered within 24 hours.
