| Manufacturer Product Number | DSPIC33FJ16GS504-H/PT |
| Manufacturer | Microchip Technology |
| NavitasChip Part Number | NAVI-3131439 |
| Description | IC MCU 16BIT 16KB FLASH 44TQFP |
| Spec | 44-TQFP |
| Package | Tray |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Microcontrollers |
| Manufacturer | Microchip Technology |
| Package | Tray |
| Product Status | Active |
| Core Processor | dsPIC |
| Core Size | 16-Bit |
| Speed | 40 MIPs |
| Connectivity | I2C, IrDA, LINbus, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Number of I/O | 35 |
| Program Memory Size | 16KB (16K x 8) |
| Program Memory Type | FLASH |
| RAM Size | 2K x 8 |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Data Converters | A/D 24x10b; D/A 4x10b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 150°C (TA) |
| Grade | Automotive |
| Qualification | AEC-Q100 |
| Mounting Type | Surface Mount |
| Supplier Device Package | 44-TQFP (10x10) |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Microchip Technology DSPIC33FJ16GS504-H/PT Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The DSPIC33FJ16GS504-H/PT is a Microcontroller (MCU) manufactured by Microchip Technology (Microchip). Integrated Circuit Microcontroller 16bit 16kb Flash Memory in 44-Pin TQFP Package, housed in a compact 44-TQFP (10x10) package. Originally developed by Maxim Integrated, this component continues to be fully supported.
In today's market, production line down can affect many manufacturers. NavitasChip offers dependable alternatives.
Key Technical Specifications
- Operating Temperature: -40°C ~ 150°C (TA)
- Mounting: Surface Mount
- Package: 44-TQFP
- Device Package: 44-TQFP (10x10)
- RoHS Compliant
Applications
Commonly utilized in:
- embedded systems
- IoT devices
- professional equipment
- industrial control
- smart home
Why Choose NavitasChip for DSPIC33FJ16GS504-H/PT?
NavitasChip offers supply gap bridging when factory lead times exceed 50 weeks for the DSPIC33FJ16GS504-H/PT and thousands of other electronic components.
- Availability: Immediate Dispatch Available
- Packaging: Available in factory Tray or Partial Tray. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
Multiple origin options for DSPIC33FJ16GS504-H/PT to optimize delivery time and customs clearance.
DSPIC33FJ16GS504-H/PT - Inquire for bulk discount.
