Image shown is a representation only.
Exact specifications should be obtained from the product data sheet.
| Manufacturer Product Number | TC9421CPD |
| Manufacturer | Microchip Technology |
| NavitasChip Part Number | NAVI-115392 |
| Description | IC OPAMP ZERO-DRIFT 1 CIRC 14DIP |
| Spec | 14-DIP (0.300", 7.62mm) |
| Package | Tube |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Category | Instrumentation, OP Amps, Buffer Amps |
| Manufacturer | Microchip Technology |
| Package | Tube |
| Product Status | Obsolete |
| Amplifier Type | Zero-Drift |
| Number of Circuits | 1 |
| Slew Rate | 0.5V/µs |
| Gain Bandwidth Product | 500 kHz |
| Current - Supply | 1.3mA |
| Voltage - Supply Span (Min) | 5 V |
| Voltage - Supply Span (Max) | 32 V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole |
| Supplier Device Package | 14-PDIP |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The TC9421CPD is an Operational Amplifier (Op Amp) manufactured by Microchip Technology (Microchip). Integrated Circuit Operational Amplifier Zero-Drift 1 Circ in 14-Pin DIP Package, housed in a compact 14-PDIP package.
Key Technical Specifications
- Operating Temperature: 0°C ~ 70°C
- Mounting: Through Hole
- Package: 14-DIP (0.300", 7.62mm)
- Device Package: 14-PDIP
Packaging: factory Tube or Custom Tube Quantity · ESD-shielded, vacuum-sealed MBB to MSL standards.
Fulfillment: MPN and Date Code verified on inbound · datasheet and compliance documents available · RFQ answered within 24 hours.
Disclaimer: NavitasChip is an independent distributor of electronic components. We are not affiliated with, endorsed by, or an authorized distributor for the manufacturers listed on this page. All trademarks and brand names are the property of their respective owners and are used solely for identification purposes.
Stock quantities are dynamic and updated in real-time. For large quantity orders (1,000+ units), please contact us for real-time stock verification and custom pricing.
