Product Attributes
| Type | Description |
|---|---|
| Category | Voltage Regulators - DC DC Switching Regulators |
| Manufacturer | onsemi |
| Package | Bulk |
| Product Status | Active |
| Function | Step-Up/Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Adjustable |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 3V |
| Voltage - Input (Max) | 60V |
| Voltage - Output (Min/Fixed) | 1.24V |
| Voltage - Output (Max) | 75V |
| Current - Output | 1.25A (Switch) |
| Frequency - Switching | 40kHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 16-SOIC |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | onsemi CS3972YDW16 Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The CS3972YDW16 is a DC-DC Switching Voltage Regulator manufactured by onsemi. Integrated Circuit Regulator Buck Adjustable 1.25a in 16-Pin SOIC Package, housed in a compact 16-SOIC package.
