Product Attributes
| Type | Description |
|---|---|
| Category | Instrumentation, OP Amps, Buffer Amps |
| Manufacturer | onsemi |
| Package | Tube |
| Product Status | Obsolete |
| Amplifier Type | Standard (General Purpose) |
| Number of Circuits | 1 |
| Slew Rate | 13V/µs |
| Gain Bandwidth Product | 10 MHz |
| Current - Input Bias | 500 nA |
| Voltage - Input Offset | 500 µV |
| Current - Supply | 4mA |
| Current - Output / Channel | 38 mA |
| Voltage - Supply Span (Min) | 6 V |
| Voltage - Supply Span (Max) | 40 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-SOIC |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | onsemi SA5534ADG Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The SA5534ADG is an Operational Amplifier (Op Amp) manufactured by onsemi. Integrated Circuit Operational Amplifier Gp 1 Circuit in 8-Pin SOIC Package, housed in a compact 8-SOIC package.
Don't let 25-year long-lifecycle industrial instrumentation requiring re-qualification when key op amp EOL announced slow down your production. We maintain ready stock for critical components.
Key Technical Specifications
- Operating Temperature: -40°C ~ 85°C
- Mounting: Surface Mount
- Package: 8-SOIC (0.154", 3.90mm Width)
- Device Package: 8-SOIC
Applications
Designed for:
- IoT devices
- rail-to-rail input and output (RRIO) op amp for single-supply low-voltage system designs
- high-voltage op amp rated 36 V to 60 V for industrial sensor front-ends and motor control
- rail-to-rail RRIO substitute for discontinued TLV9061, TLV2371, OPA340 and OPA350 single-supply parts
Why Choose NavitasChip for SA5534ADG?
NavitasChip offers global surplus sourcing network for the SA5534ADG and thousands of other electronic components.
- Availability: Ready to Ship
- Packaging: Available in factory Tube or Custom Tube Quantity. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
Need SA5534ADG urgently? We maintain buffer stock across multiple global locations.
SA5534ADG - Upload your BOM for fast pricing.
