| Manufacturer Product Number | APT1232AX |
| Manufacturer | Panasonic Electric Works |
| NavitasChip Part Number | NAVI-8031622 |
| Description | OPTOISOLTR 5KV TRIAC 1CH 6DIP GW |
| Spec | 6-SMD (5 Leads), Gull Wing |
| Package | Tape & Reel (TR) |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Triac, SCR Output Optoisolators |
| Manufacturer | Panasonic Electric Works |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| Output Type | Triac |
| Zero Crossing Circuit | Yes |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Voltage - Off State | 600 V |
| Static dV/dt (Min) | 500V/µs |
| Current - LED Trigger (Ift) (Max) | 10mA |
| Current - On State (It (RMS)) (Max) | 100 mA |
| Current - Hold (Ih) | 3.5mA |
| Turn On Time | 100µs (Max) |
| Voltage - Forward (Vf) (Typ) | 1.21V |
| Current - DC Forward (If) (Max) | 50 mA |
| Operating Temperature | -40°C ~ 100°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 6-DIP Gull Wing |
| Approval Agency | cUR, VDE |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Panasonic Electric Works APT1232AX Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The APT1232AX is an Optocoupler manufactured by Panasonic Electric Works. Optocoupler Isolator 5kV Triac 1-Channel in 6-Pin DIP Package Gull Wing, housed in a compact 6-DIP Gull Wing package.
Key Technical Specifications
- Output Type: Triac
- Channels: 1
- Operating Temperature: -40°C ~ 100°C
- Mounting: Surface Mount
- Package: 6-SMD (5 Leads), Gull Wing
- Device Package: 6-DIP Gull Wing
- RoHS Compliant
