| Manufacturer Product Number | MN101CF49KXN |
| Manufacturer | Panasonic Electronic Components |
| NavitasChip Part Number | NAVI-705608 |
| Description | IC MCU 8BIT 224KB FLASH 100QFP |
| Spec | 100-BQFP |
| Package | Tray |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Microcontrollers |
| Manufacturer | Panasonic Electronic Components |
| Package | Tray |
| Product Status | Obsolete |
| Core Processor | MN101C |
| Core Size | 8-Bit |
| Speed | 20MHz |
| Connectivity | I2C, UART/USART |
| Peripherals | DMA, PWM, WDT |
| Number of I/O | 73 |
| Program Memory Size | 224KB (224K x 8) |
| Program Memory Type | FLASH |
| RAM Size | 10K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2V ~ 5.5V |
| Data Converters | A/D 8x10b; D/A 4x8b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 100-QFP (18x18) |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Panasonic Electronic Components MN101CF49KXN Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The MN101CF49KXN is a Microcontroller (MCU) manufactured by Panasonic Electronic Components (Panasonic). Integrated Circuit Microcontroller 8bit 224kb Flash Memory in 100-Pin QFP Package, housed in a compact 100-QFP (18x18) package.
Key Technical Specifications
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting: Surface Mount
- Package: 100-BQFP
- Device Package: 100-QFP (18x18)
Packaging: factory Tray or Partial Tray · ESD-shielded, vacuum-sealed MBB to MSL standards.
Fulfillment: MPN and Date Code verified on inbound · datasheet and compliance documents available · RFQ answered within 24 hours.
