| Manufacturer Product Number | EL5224IRE |
| Manufacturer | Renesas Electronics Corporation |
| NavitasChip Part Number | NAVI-1061364 |
| Description | IC BUFFER 8 CIRCUIT 24HTSSOP |
| Spec | 24-TSSOP (0.173", 4.40mm Width) Exposed Pad |
| Package | Tube |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Instrumentation, OP Amps, Buffer Amps |
| Manufacturer | Renesas Electronics Corporation |
| Package | Tube |
| Product Status | Obsolete |
| Amplifier Type | Buffer |
| Number of Circuits | 8 |
| Output Type | Rail-to-Rail |
| Slew Rate | 15V/µs |
| Gain Bandwidth Product | 8 MHz |
| -3db Bandwidth | 12 MHz |
| Current - Input Bias | 2 nA |
| Voltage - Input Offset | 2 mV |
| Current - Supply | 6.8mA (x8 Channels) |
| Current - Output / Channel | 140 mA |
| Voltage - Supply Span (Min) | 4.5 V |
| Voltage - Supply Span (Max) | 16.5 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 24-HTSSOP |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Renesas Electronics Corporation EL5224IRE Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The EL5224IRE is an Operational Amplifier (Op Amp) manufactured by Renesas Electronics Corporation (Renesas). Integrated Circuit Buffer 8 Circuit 24htssop, housed in a compact 24-HTSSOP package. Originally developed by Intersil, this component continues to be fully supported. Extended temperature range version (-40°C to +85°C).
In today's market, LT1006, LT1077, LT1097 and LT1357 Linear legacy precision op amps as spot buy gold for industrial test equipment refurbishment can affect many manufacturers. NavitasChip offers dependable alternatives.
Key Technical Specifications
- Output Type: Rail-to-Rail
- Operating Temperature: -40°C ~ 85°C
- Mounting: Surface Mount
- Package: 24-TSSOP (0.173", 4.40mm Width) Exposed Pad
- Device Package: 24-HTSSOP
Applications
Perfect for:
- voltage-feedback (VFA) and current-feedback (CFA) op amp architectures for closed-loop signal chains
- high-side and low-side current sensing for lithium battery packs, BMS and brushless motor phase monitoring
- photodiode transimpedance amplification, active filter design and analog computational stages in optical sensing
Why Choose NavitasChip for EL5224IRE?
NavitasChip offers wholesale pricing advantages for the EL5224IRE and thousands of other electronic components.
- Availability: Ready to Ship
- Packaging: Available in factory Tube or Custom Tube Quantity. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
EL5224IRE sourced and shipped via our Asia-Pacific distribution network.
EL5224IRE - Request a quote today.
