| Manufacturer Product Number | PC942 |
| Manufacturer | Sharp Microelectronics |
| NavitasChip Part Number | NAVI-458051 |
| Description | OPTOISO 5KV PWR TRANS DVR 8DIP |
| Spec | 8-DIP (0.300", 7.62mm) |
| Package | Tube |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Special Purpose Isolators |
| Manufacturer | Sharp Microelectronics |
| Package | Tube |
| Product Status | Obsolete |
| Type | Power Transistor Driver |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 10kV/µs |
| Input Type | DC |
| Current - Output / Channel | 500mA, 600mA |
| Propagation Delay tpLH / tpHL (Max) | 5µs, 5µs |
| Rise / Fall Time (Typ) | 200ns, 100ns |
| Voltage - Forward (Vf) (Typ) | 1.1 V |
| Current - DC Forward (If) (Max) | 25 mA |
| Voltage - Supply | 5.4V ~ 13V |
| Operating Temperature | -20°C ~ 80°C |
| Mounting Type | Through Hole |
| Supplier Device Package | 8-DIP |
| Approval Agency | UR |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Sharp Microelectronics PC942 Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The PC942 is an Isolator manufactured by Sharp Microelectronics (Sharp). Optocoupler Isolator 5kV Power Trans Driver in 8-Pin DIP Package, housed in a compact 8-DIP package, with 5.4V ~ 13V supply voltage.
Struggling with EOL (End of Life) notices? Our global sourcing network ensures reliable supply for your projects.
Key Technical Specifications
- Supply Voltage: 5.4V ~ 13V
- Channels: 1
- Operating Temperature: -20°C ~ 80°C
- Mounting: Through Hole
- Package: 8-DIP (0.300", 7.62mm)
- Device Package: 8-DIP
Applications
Designed for:
- industrial fieldbus
- power supplies
- industrial control
Why Choose NavitasChip for PC942?
NavitasChip offers competitive market pricing for the PC942 and thousands of other electronic components.
- Availability: In Inventory
- Packaging: Available in factory Tube or Custom Tube Quantity. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
