| Manufacturer Product Number | ADS54J20IRMP |
| Manufacturer | Texas Instruments |
| NavitasChip Part Number | NAVI-6164976 |
| Description | IC ADC 12BIT PIPELINED 72VQFN |
| Spec | 72-VFQFN Exposed Pad |
| Package | Tray |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Analog to Digital Converters (ADC) |
| Manufacturer | Texas Instruments |
| Package | Tray |
| Product Status | Active |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 1G |
| Number of Inputs | 2 |
| Input Type | Differential |
| Data Interface | JESD204B |
| Configuration | ADC |
| Number of A/D Converters | 2 |
| Architecture | Pipelined |
| Reference Type | Internal |
| Voltage - Supply, Analog | 1.8V ~ 2V, 2.85V ~ 3.6V |
| Voltage - Supply, Digital | 1.7V ~ 2V |
| Features | Simultaneous Sampling |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 72-VQFN (10x10) |
| Mounting Type | Surface Mount |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Texas Instruments ADS54J20IRMP Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The ADS54J20IRMP is an Analog-to-Digital Converter (ADC) manufactured by Texas Instruments (TI). Integrated Circuit Analog-To-Digital Converter 12bit Pipelined 72vqfn, housed in a compact 72-VQFN (10x10) package.
Struggling with distributor allocation reducing high-resolution ADC availability? Our global sourcing network ensures reliable supply for your projects.
Key Technical Specifications
- Operating Temperature: -40°C ~ 85°C
- Mounting: Surface Mount
- Package: 72-VFQFN Exposed Pad
- Device Package: 72-VQFN (10x10)
- RoHS Compliant
