| Manufacturer Product Number | ADS7820PB |
| Manufacturer | Texas Instruments |
| NavitasChip Part Number | NAVI-11533259 |
| Description | IC 12-BIT 100KHZ SMPL A/D 28-DIP |
| Spec | 28-DIP (0.600", 15.24mm) |
| Package | Tube |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Analog to Digital Converters (ADC) |
| Manufacturer | Texas Instruments |
| Package | Tube |
| Product Status | Obsolete |
| Number of Bits | 12 |
| Sampling Rate (Per Second) | 100k |
| Number of A/D Converters | 1 |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 28-DIP |
| Mounting Type | Through Hole |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Texas Instruments ADS7820PB Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The ADS7820PB is an Analog-to-Digital Converter (ADC) manufactured by Texas Instruments (TI). Integrated Circuit 12-Bit 100kHz Smpl Analog-To-Digital in 28-Pin DIP Package, housed in a compact 28-DIP package.
