| Manufacturer Product Number | OPA3684ID |
| Manufacturer | Texas Instruments |
| NavitasChip Part Number | NAVI-509674 |
| Description | IC OPAMP CFA 3 CIRCUIT 14SOIC |
| Spec | 14-SOIC (0.154", 3.90mm Width) |
| Package | Bulk |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Instrumentation, OP Amps, Buffer Amps |
| Manufacturer | Texas Instruments |
| Package | Bulk |
| Product Status | Active |
| Amplifier Type | Current Feedback |
| Number of Circuits | 3 |
| Slew Rate | 780V/µs |
| Gain Bandwidth Product | 1.9 GHz |
| -3db Bandwidth | 250 MHz |
| Current - Input Bias | 5 µA |
| Voltage - Input Offset | 1.5 mV |
| Current - Supply | 1.7mA |
| Current - Output / Channel | 160 mA |
| Voltage - Supply Span (Min) | 2.8 V |
| Voltage - Supply Span (Max) | 12 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOIC |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Texas Instruments OPA3684ID Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The OPA3684ID is an Operational Amplifier (Op Amp) manufactured by Texas Instruments (TI). Integrated Circuit Operational Amplifier Cfa 3 Circuit in 14-Pin SOIC Package, housed in a compact 14-SOIC package.
Key Technical Specifications
- Operating Temperature: -40°C ~ 85°C
- Mounting: Surface Mount
- Package: 14-SOIC (0.154", 3.90mm Width)
- Device Package: 14-SOIC
- RoHS Compliant
Packaging: factory Bulk or Custom Quantity · ESD-shielded, vacuum-sealed MBB to MSL standards.
Fulfillment: MPN and Date Code verified on inbound · datasheet and compliance documents available · RFQ answered within 24 hours.
