| Manufacturer Product Number | AD7804BRZ-REEL |
| Manufacturer | Analog Devices Inc. |
| NavitasChip Part Number | NAVI-619661 |
| Description | IC DAC 10BIT V-OUT 16SOIC |
| Spec | 16-SOIC (0.295", 7.50mm Width) |
| Package | Tape & Reel (TR) |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Digital to Analog Converters (DAC) |
| Manufacturer | Analog Devices Inc. |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| Number of Bits | 10 |
| Number of D/A Converters | 4 |
| Settling Time | 4µs |
| Output Type | Voltage - Buffered |
| Differential Output | No |
| Data Interface | SPI |
| Reference Type | External, Internal |
| Voltage - Supply, Analog | 3V ~ 5.5V |
| Voltage - Supply, Digital | 3V ~ 5.5V |
| INL/DNL (LSB) | ±3 (Max), ±0.125 |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 16-SOIC |
| Mounting Type | Surface Mount |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc. AD7804BRZ-REEL Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The AD7804BRZ-REEL is a Digital-to-Analog Converter (DAC) manufactured by Analog Devices Inc. (ADI). Integrated Circuit Digital-To-Analog Converter 10bit V-Out in 16-Pin SOIC Package, housed in a compact 16-SOIC package. Tape and Reel packaging available.
Struggling with end-of-life DAC transition without firmware or analog circuit redesign? Our global sourcing network ensures reliable supply for your projects.
Key Technical Specifications
- Output Type: Voltage - Buffered
- Operating Temperature: -40°C ~ 85°C
- Mounting: Surface Mount
- Package: 16-SOIC (0.295", 7.50mm Width)
- Device Package: 16-SOIC
- RoHS Compliant
Applications
Designed for:
- voltage-output DAC with integrated buffer for direct load driving
- monotonic guaranteed output for stable feedback control loops
- test and measurement instrumentation and bench equipment
Why Choose NavitasChip for AD7804BRZ-REEL?
NavitasChip offers Allocated parts in stock when authorized channels face shortage for the AD7804BRZ-REEL and thousands of other electronic components.
- Availability: Same-day Shipping Options
- Packaging: Available in factory Tape & Reel (TR) or Cut Tape. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
We offer express global shipping for AD7804BRZ-REEL, serving customers in Singapore, South Korea, and worldwide.
AD7804BRZ-REEL - Get instant quote online.
