| Manufacturer Product Number | AD9136BCPZRL |
| Manufacturer | Analog Devices Inc. |
| NavitasChip Part Number | NAVI-5056848 |
| Description | IC DAC 16BIT A-OUT 88LFCSP |
| Spec | 88-VFQFN Exposed Pad, CSP |
| Package | Tape & Reel (TR) |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Digital to Analog Converters (DAC) |
| Manufacturer | Analog Devices Inc. |
| Package | Tape & Reel (TR) |
| Product Status | Active |
| Number of Bits | 16 |
| Number of D/A Converters | 2 |
| Settling Time | 20ns (Typ) |
| Output Type | Current - Unbuffered |
| Differential Output | Yes |
| Data Interface | JESD204B |
| Reference Type | Internal |
| Voltage - Supply, Analog | 3.13V ~ 3.47V |
| Voltage - Supply, Digital | 1.14V ~ 1.26V |
| INL/DNL (LSB) | ±2, ±1 |
| Architecture | Current Source |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 88-LFCSP-VQ (12x12) |
| Mounting Type | Surface Mount |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc. AD9136BCPZRL Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The AD9136BCPZRL is a Digital-to-Analog Converter (DAC) manufactured by Analog Devices Inc. (ADI). Integrated Circuit Digital-To-Analog Converter 16bit A-Out in 88-Pin Csp Package, housed in a compact 88-LFCSP-VQ (12x12) package.
Don't let challenging Target Price (TP) requirements slow down your production. We maintain ready stock for critical components.
Key Technical Specifications
- Output Type: Current - Unbuffered
- Operating Temperature: -40°C ~ 85°C
- Mounting: Surface Mount
- Package: 88-VFQFN Exposed Pad, CSP
- Device Package: 88-LFCSP-VQ (12x12)
- RoHS Compliant
Applications
Ideal solution for:
- industrial automation
- R-2R ladder and segmented DAC architectures for monotonic output
- current-output DAC for industrial 4-20 mA loop and laser driver applications
- communication waveform synthesis and signal generation platforms
