| Manufacturer Product Number | MAX5735BUTN+T |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| NavitasChip Part Number | NAVI-1938076 |
| Description | IC DAC 16BIT V-OUT 56TQFN |
| Spec | 56-WFQFN Exposed Pad |
| Package | Tape & Reel (TR) |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Digital to Analog Converters (DAC) |
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Package | Tape & Reel (TR) |
| Product Status | Discontinued at |
| Number of Bits | 16 |
| Number of D/A Converters | 32 |
| Settling Time | 20µs (Typ) |
| Output Type | Voltage - Buffered |
| Differential Output | No |
| Data Interface | SPI, DSP |
| Reference Type | External |
| Voltage - Supply, Analog | 5V |
| Voltage - Supply, Digital | 2.7V ~ 5.25V |
| INL/DNL (LSB) | ±8, ±1 (Max) |
| Architecture | Pipelined |
| Operating Temperature | 0°C ~ 85°C |
| Supplier Device Package | 56-TQFN (8x8) |
| Mounting Type | Surface Mount |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Analog Devices Inc./Maxim Integrated MAX5735BUTN+T Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The MAX5735BUTN+T is a Digital-to-Analog Converter (DAC) manufactured by Analog Devices Inc./Maxim Integrated (ADI-Maxim). Integrated Circuit Digital-To-Analog Converter 16bit V-Out 56tqfn, housed in a compact 56-TQFN (8x8) package. Originally developed by Maxim Integrated, this component continues to be fully supported.
Don't let EOL (End of Life) notices slow down your production. We maintain ready stock for critical components.
Key Technical Specifications
- Output Type: Voltage - Buffered
- Operating Temperature: 0°C ~ 85°C
- Mounting: Surface Mount
- Package: 56-WFQFN Exposed Pad
- Device Package: 56-TQFN (8x8)
- RoHS Compliant
Applications
Perfect for:
- IoT devices
- R-2R ladder and segmented DAC architectures for monotonic output
- 18-bit and 20-bit ultra-high resolution DAC for metrology and test equipment
- monotonic guaranteed output for stable feedback control loops
- communication waveform synthesis and signal generation platforms
Why Choose NavitasChip for MAX5735BUTN+T?
NavitasChip offers cost-saving procurement for the MAX5735BUTN+T and thousands of other electronic components.
- Availability: In Inventory
- Packaging: Available in factory Tape & Reel (TR) or Cut Tape. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
Fast MAX5735BUTN+T delivery to United Kingdom and Germany via DHL, FedEx, and UPS.
MAX5735BUTN+T - Upload your BOM for fast pricing.
