| Manufacturer Product Number | HCPL-7520-300 |
| Manufacturer | Broadcom Limited |
| NavitasChip Part Number | NAVI-637403 |
| Description | IC CURR SENSE 1 CIRCUIT 8DIPGW |
| Spec | 8-SMD, Gull Wing |
| Package | Tube |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Instrumentation, OP Amps, Buffer Amps |
| Manufacturer | Broadcom Limited |
| Package | Tube |
| Product Status | Active |
| Amplifier Type | Current Sense |
| Number of Circuits | 1 |
| -3db Bandwidth | 100 kHz |
| Current - Input Bias | 600 nA |
| Voltage - Input Offset | 600 µV |
| Current - Supply | 11.7mA |
| Current - Output / Channel | 16 mA |
| Voltage - Supply Span (Min) | 4.5 V |
| Voltage - Supply Span (Max) | 5.5 V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-DIP Gull Wing |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Broadcom Limited HCPL-7520-300 Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The HCPL-7520-300 is an Operational Amplifier (Op Amp) manufactured by Broadcom Limited (Broadcom). Integrated Circuit Curr Sense 1 Circuit 8dipgw, housed in a compact 8-DIP Gull Wing package.
Facing digital isolator shortage? NavitasChip provides agile sourcing solutions to keep your production running.
Key Technical Specifications
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting: Surface Mount
- Package: 8-SMD, Gull Wing
- Device Package: 8-DIP Gull Wing
Applications
Designed for:
- IoT devices
- JFET-input and FET-input op amp for high input impedance and low bias current photometry stages
- current sense amplifier for high-side and bidirectional battery and motor current monitoring
- high-side and low-side current sensing for lithium battery packs, BMS and brushless motor phase monitoring
Why Choose NavitasChip for HCPL-7520-300?
NavitasChip offers wholesale pricing advantages for the HCPL-7520-300 and thousands of other electronic components.
- Availability: Ready to Ship
- Packaging: Available in factory Tube or Custom Tube Quantity. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
Multiple origin options for HCPL-7520-300 to optimize delivery time and customs clearance.
HCPL-7520-300 - Request a quote today.
