Image shown is a representation only.
Exact specifications should be obtained from the product data sheet.
| Manufacturer Product Number | 74LVC16344APAG |
| Manufacturer | IDT, Integrated Device Technology Inc |
| NavitasChip Part Number | NAVI-12096645 |
| Description | IC CLK BUFFER 2:4 56TSSOP |
| Spec | 56-TFSOP (0.240", 6.10mm Width) |
| Package | Bulk |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Clock Buffers, Drivers |
| Manufacturer | IDT, Integrated Device Technology Inc |
| Package | Bulk |
| Product Status | Active |
| Type | Fanout Buffer (Distribution) |
| Number of Circuits | 4 |
| Ratio - Input | 2:4 |
| Differential - Input | No/No |
| Input | Clock |
| Output | 3-State |
| Voltage - Supply | 2.3V ~ 3.6V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 56-TSSOP |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | IDT, Integrated Device Technology Inc 74LVC16344APAG Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The 74LVC16344APAG is a Clock Buffer and Driver IC manufactured by IDT, Integrated Device Technology Inc (IDT). Integrated Circuit Clock Buffer 2:4 in 56-Pin TSSOP Package, housed in a compact 56-TSSOP package, with 2.3V ~ 3.6V supply voltage.
Key Technical Specifications
- Supply Voltage: 2.3V ~ 3.6V
- Operating Temperature: -40°C ~ 85°C
- Mounting: Surface Mount
- Package: 56-TFSOP (0.240", 6.10mm Width)
- Device Package: 56-TSSOP
- RoHS Compliant
Packaging: factory Bulk or Custom Quantity · ESD-shielded, vacuum-sealed MBB to MSL standards.
Fulfillment: MPN and Date Code verified on inbound · datasheet and compliance documents available · RFQ answered within 24 hours.
