| Manufacturer Product Number | MC56F8002VWLR |
| Manufacturer | NXP USA Inc. |
| NavitasChip Part Number | NAVI-7646033 |
| Description | IC MCU 16BIT 12KB FLASH 28SOIC |
| Spec | 28-SOIC (0.295\ |
| Package | Tape & Reel (TR) |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Microcontrollers |
| Manufacturer | NXP USA Inc. |
| Package | Tape & Reel (TR) |
| Product Status | Last Time Buy |
| Core Processor | 56800E |
| Core Size | 16-Bit |
| Speed | 32MHz |
| Connectivity | I2C, LINbus, SCI, SPI |
| Peripherals | LVD, POR, PWM, WDT |
| Number of I/O | 23 |
| Program Memory Size | 12KB (6K x 16) |
| Program Memory Type | FLASH |
| RAM Size | 1K x 16 |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 3.6V |
| Data Converters | A/D 15x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 28-SOIC |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | NXP USA Inc. MC56F8002VWLR Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The MC56F8002VWLR is a Microcontroller (MCU) manufactured by NXP USA Inc. (NXP). Integrated Circuit Microcontroller 16bit 12kb Flash Memory in 28-Pin SOIC Package, housed in a compact 28-SOIC package.
Facing microcontroller shortage? NavitasChip provides agile sourcing solutions to keep your production running.
Key Technical Specifications
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting: Surface Mount
- Package: 28-SOIC (0.295\
- Device Package: 28-SOIC
- RoHS Compliant
Applications
Ideal solution for:
- embedded systems
- professional equipment
- wearable devices
- industrial control
- smart home
Why Choose NavitasChip for MC56F8002VWLR?
NavitasChip offers competitive market pricing for the MC56F8002VWLR and thousands of other electronic components.
- Availability: Available Now
- Packaging: Available in factory Tape & Reel (TR) or Cut Tape. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
We offer express global shipping for MC56F8002VWLR, serving customers in Romania, Czech Republic, and worldwide.
MC56F8002VWLR - Check our competitive price now.
