| Manufacturer Product Number | MC56F8011VFAE |
| Manufacturer | NXP USA Inc. |
| NavitasChip Part Number | NAVI-15636953 |
| Description | MC56F8011 - 16-BIT DSC, 56800E C |
| Spec | 32-LQFP |
| Package | Bulk |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Microcontrollers |
| Manufacturer | NXP USA Inc. |
| Package | Bulk |
| Product Status | Active |
| Core Processor | 56800E |
| Core Size | 16-Bit |
| Speed | 32MHz |
| Connectivity | I2C, SCI, SPI |
| Peripherals | POR, PWM, WDT |
| Number of I/O | 26 |
| Program Memory Size | 12KB (6K x 16) |
| Program Memory Type | FLASH |
| RAM Size | 1K x 16 |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V |
| Data Converters | A/D 6x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 32-LQFP (7x7) |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | NXP USA Inc. MC56F8011VFAE Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The MC56F8011VFAE is a Microcontroller (MCU) manufactured by NXP USA Inc. (NXP). Mc56f8011 - 16-Bit Dsc, housed in a compact 32-LQFP (7x7) package. Extended temperature range version (-40°C to +85°C).
Don't let minimum order quantity requirements slow down your production. We maintain ready stock for critical components.
Key Technical Specifications
- Operating Temperature: -40°C ~ 105°C (TA)
- Mounting: Surface Mount
- Package: 32-LQFP
- Device Package: 32-LQFP (7x7)
Applications
Critical part of:
- embedded systems
- industrial control
- smart home
Why Choose NavitasChip for MC56F8011VFAE?
NavitasChip offers cost-saving procurement for the MC56F8011VFAE and thousands of other electronic components.
- Availability: Immediate Dispatch Available
- Packaging: Available in factory Bulk or Custom Quantity. All custom quantities are professionally repackaged with ESD Shielding and Vacuum-Sealed MBB (Moisture Barrier Bags) in strict adherence to MSL standards.
- Fast Shipping: Ships from Shenzhen / Hong Kong / Singapore via DHL/FedEx/UPS
- Quality Assurance: Inbound check with MPN and Date Code review
- Technical Support: Datasheet and compliance documentation available
Global Shipping
Multiple origin options for MC56F8011VFAE to optimize delivery time and customs clearance.
MC56F8011VFAE - Request a quote today.
