| Manufacturer Product Number | PCA9691BS/1,118 |
| Manufacturer | NXP USA Inc. |
| NavitasChip Part Number | NAVI-2034326 |
| Description | IC ADC/DAC 8BIT 16HVQFN |
| Spec | 16-VQFN Exposed Pad |
| Package | Tape & Reel (TR) |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | ADCs/DACs - Special Purpose |
| Manufacturer | NXP USA Inc. |
| Package | Tape & Reel (TR) |
| Product Status | Obsolete |
| Type | ADC, DAC |
| Number of Channels | 4 |
| Resolution (Bits) | 8 b |
| Data Interface | I2C, Serial |
| Voltage Supply Source | Single Supply |
| Voltage - Supply | 2.5V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 16-HVQFN (4x4) |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | NXP USA Inc. PCA9691BS/1,118 Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The PCA9691BS/1,118 is an Audio Codec and Special-Purpose Data Converter IC manufactured by NXP USA Inc. (NXP). Integrated Circuit Analog-To-Digital Converter/digital-To-Analog Converter 8bit 16hvqfn, housed in a compact 16-HVQFN (4x4) package, with 2.5V ~ 5.5V supply voltage.
