Image shown is a representation only.
Exact specifications should be obtained from the product data sheet.
| Manufacturer Product Number | PI3526-00-BGIZ |
| Manufacturer | Vicor Corporation |
| NavitasChip Part Number | NAVI-12503834 |
| Description | IC REG BUCK 12V 18A 110BGA |
| Spec | 110-BBGA Module |
| Package | Tray |
| Datasheet | Datasheet |
Product Attributes
| Type | Description |
|---|---|
| Category | Voltage Regulators - DC DC Switching Regulators |
| Manufacturer | Vicor Corporation |
| Tariff Status | Tariff may apply if shipping to the United States |
| Package | Tray |
| Product Status | Obsolete |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Output Type | Fixed |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 30V |
| Voltage - Input (Max) | 60V |
| Voltage - Output (Min/Fixed) | 12V |
| Current - Output | 18A |
| Frequency - Switching | 7MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 120°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 110-BGA (14.5x10.5) |
| Part Status | Active |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheet | Vicor Corporation PI3526-00-BGIZ Datasheet |
| Product Image | View Large Image |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | RoHS Compliant |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
Product Description
The PI3526-00-BGIZ is a DC-DC Switching Voltage Regulator manufactured by Vicor Corporation. Integrated Circuit Regulator Buck 12V Supply 18a in 110-Pin BGA Package, housed in a compact 110-BGA (14.5x10.5) package.
Key Technical Specifications
- Output Type: Fixed
- Operating Temperature: -40°C ~ 120°C
- Mounting: Surface Mount
- Package: 110-BBGA Module
- Device Package: 110-BGA (14.5x10.5)
- RoHS Compliant
Packaging: factory Tray or Partial Tray · ESD-shielded, vacuum-sealed MBB to MSL standards.
